26㎡Villa
Standard (1 Bedrooms)
● Area of the house is 26㎡, one floor. The indoor height is 2.3m.
Specifications：
● 4.27m (L) x 5.98m (W) x 2.65m (H)
● Floor - Applied 100*80 steel frame (Q355, wall thickness 2.5mm), the square tube is galvanzied and sprayed with plastic. 0.426mm Colored Steel Sheet (Surface AZM100g/m2+PE coated 20/5um)+ Steel Frame+ Filled with 100mm PU for insulation + 8mm SPC Stone Plastic.
● Front and Back Wall of the General Kitchen and Bathroom Module - Applied 80*80 steel frame (Q355, wall thickness 2.5mm), the square tube is galvanzied and sprayed with plastic. 7.5mm Plank（surface is brushed with 500g/m2 wood oil）+ Steel Frame + 80mm PU +9mm Bamboo and Wood Fiberboard (Width 600mm).
● Side Wall of the General Kitchen and Bathroom Module - Applied 80*80 steel frame (Q355, wall thickness 1.5mm) is galvanzied and sprayed with plastic. 27mm Craved Metal Board + 9mm OSB Board + Steel Frame + 50mm Glass• Wool + 9mmOSB Board + 9mm Bamboo and Wood Fiberboard (Width 600mm).
● Partition Wall of the General Kitchen and Bathroom Module - Applied 50*50 steel frame (Q355, wall thickness 1.5mm) is galvanzied and sprayed with plastic. 9mm Bamboo and Wood Fiberboard (Width 600mm) + 9mm OSB Board + Steel Frame + 50mm Glass Wool + 9mm OSB Board + 9mm Bamboo and Wood Fiberboard (Width 600mm).
● Ceiling Board - Applied 80*80 steel frame (Q355, wall thickness 2.5mm),the square tube is galvanzied and sprayed with plastic. 0.426mm Colored Steel Sheet (Surface AZM100g/m2+PE coated 20/5um)+ Steel Frame + 80mm PU + 9mm Bamboo and Wood Fiberboard (Width 600mm).
● Foldable Walls - Applied 75*68 (convex 18) frame (wall thickness 1.8mm), and sprayed with plastic. 27mm Craved Metal Board + Steel Frame +75mm PU + 9mm Bamboo and Wood Fiberboard (Width 600mm).
● Doors - Aluminum Alloy Double Do, Wooden Single Door with Steel Frame.
● Windows - Aluminum Casement Window/Top-Hung Window.
● Furniture - L-Shaped Cabinet (Floor Cabinet included) *1.
● Sanitary - Procelain Toilet *1, Wash Basin *1, Shower Room *1.
● Industry leading 5-year structural warranty.
Are you looking for a warm and comfortable cabin? Then the 26㎡ villa will be a good choice，Our 26m² villa/granny flat consists of 1 bedroom, 1 bathroom, 1 living room, kitchen, shower room and wash basin. ,Please contact us for more information about our 26m² villa/granny flat.
Due to continued product improvements, the images shown on our website may vary slightly from the actual product. Decks, pergolas, trailers, furniture ect are not included.
39.8㎡Villa
Standard (2 Bedrooms)
● Area of the house is 26㎡, one floor. The indoor height is 2.3m.
Specifications：
● 6.67m (L) x 5.98m (W) x 2.65m (H)
● Floor - Applied 100*80 steel frame (Q355, wall thickness 2.5mm), the square tube is galvanzied and sprayed with plastic. 0.426mm Colored Steel Sheet (Surface AZM100g/m2+PE coated 20/5um)+ Steel Frame+ Filled with 100mm PU for insulation + 8mm SPC Stone Plastic .
● Front and Back Wall of the General Kitchen and Bathroom Module - Applied 80*80 steel frame (Q355, wall thickness 2.5mm), the squaretube is galvanzied and sprayed with plastic. 7.5mm Plank（surface is brushed with 500g/m2 wood oil）+ Steel Frame + 80mm PU +9mm Bamboo and Wood Fiberboard (Width 600mm).
● Side Wall of the General Kitchen and Bathroom Module - Applied 80*80 steel frame (Q355, wall thickness 1.5mm) is galvanzied and sprayed with plastic. 27mm Craved Metal Board + 9mm OSB Board + Steel Frame + 50mm Glass• Wool + 9mmOSB Board + 9mm Bamboo and Wood Fiberboard (Width 600mm).
● Partition Wall of the General Kitchen and Bathroom Module - Applied 50*50 steel frame (Q355, wall thickness 1.5mm) is galvanzied and sprayed with plastic. 9mm Bamboo and Wood Fiberboard (Width 600mm) + 9mm OSB Board + Steel Frame + 50mm Glass Wool + 9mm OSB Board + 9mm Bamboo and Wood Fiberboard (Width 600mm).
● Ceiling Board - Applied 80*80 steel frame (Q355, wall thickness 2.5mm),the square tube is galvanzied and sprayed with plastic. 0.426mm Colored Steel Sheet (Surface AZM100g/m2+PE coated 20/5um)+ Steel Frame + 80mm PU + 9mm Bamboo and Wood Fiberboard (Width 600mm).
● Foldable Walls - Applied 75*68 (convex 18) frame (wall thickness 1.8mm), and sprayed with plastic. 27mm Craved Metal Board + Steel Frame +75mm PU + 9mm Bamboo and Wood Fiberboard (Width 600mm).
● Doors - Aluminum Alloy Double Do, Wooden Single Door with Steel Frame.
● Windows - Aluminum Casement Window/Top-Hung Window.
● Furniture - L-Shaped Cabinet (Floor Cabinet included) *1.
● Sanitary - Procelain Toilet *1, Wash Basin *1, Shower Room *1.
● Industry leading 5-year structural warranty.
Our 39.8m² villa/granny flat consists of 2 bedrooms, 1 bathroom, 1 living room, kitchen, shower room and wash basin. Ideal for those with a larger space,
please contact us for more information about our 39.8m² mobile home/granny flat.
Due to continued product improvements, the images shown on our website may vary slightly from the actual product. Decks, pergolas, trailers, furniture ect are not included.
Own your new granny flat today！
